RCINPOWER WASP MAJOR EVO PLUS 22.6-7.2 - 2200KV

The RCINPOWER Wasp Major EVO Plus 22.6-7.2 2200KV motor is a ultra-high-performance brushless motor specifically built for aggressive 5-inch FPV racing and freestyle drones. Featuring an expanded 22.6x7.2mm stator structure, this motor delivers increased torque, exceptional punch out, and instantaneous throttle response on 5S and 6S LiPo power configurations.

Also check out our other 22xx motors and all our RCINPOWER products!

Features:

• Oversized 22.6x7.2mm stator configuration engineered for extreme torque and acceleration

• High-performance 2200KV rating optimized for high-speed 5S-6S FPV setups

• Ultra-durable 7075-T6 aluminum bell design with reinforced structure

• Curved N52H magnets for maximum magnetic efficiency and smooth power delivery

• High-temperature single-strand oxygen-free copper windings rated to resist extreme heat

• Active cooling housing design to minimize operating temperatures during high loads

• Standard M5 hollow shaft and 16x16mm mounting pattern for wide frame compatibility

Specifications:

• Motor Dimensions: 27.2mm x 17.8mm

• Stator Diameter: 22.6mm

• Stator Height: 7.2mm

• KV Rating: 2200KV

• Configuration: 12N14P

• Input Voltage: 5S–6S LiPo

• Weight: 30.3g (with wires)

• Shaft Diameter: 5mm hollow shaft

• Mounting Pattern: 16x16mm

• Wire Gauge: 20AWG 150mm silicone wire

• Internal Resistance: 38mΩ

• Maximum Current: 60.3A

• Maximum Power: 1447W

Package Includes:

• 1 x RCINPOWER Wasp Major EVO Plus 22.6-7.2 2200KV Brushless Motor

• 1 x Hardware Screw Pack

• 1 x Propeller Lock Nut
