HAKRC F4126 BLHELI_S 35A WHOOP AIO FC - 25×25mm

The HAKRC F4126 BLHELI_S 35A WHOOP AIO FC is a high-performance all-in-one flight controller and electronic speed controller board designed specifically for ultralight and whoop-style drone builds. Combining reliable power handling with advanced processing and a rare built-in barometer, this board is engineered to elevate your lightweight multirotor setup.

Checkout all our Whoop Style Flight Controllers and the rest of our HAKRC products!

Features:

• PCB adopts high-end 8-layer 2oZ thickened copper skin, providing stronger overcurrent capability and excellent heat dissipation

• MOS adopts imported 30V high current resistance mos for long life and strong load capacity

• Equipped with industrial-grade LDO for high temperature resistance

• Utilizes high-quality Japanese Murata capacitors for strong filtering performance

• Features an integrated barometer for enhanced altitude tracking capabilities

Specifications:

• Item: HAKRC F4126 BLHELI_S 35A WHOOP AIO FC

• CPU: STM32F411CEU6

• IMU: ICM42688

• OSD: AT7456E

• Barometer: BMP280

• Sensor: Built-in current sensor

• Flight Control Firmware Version: HAKRCF411D

• Input Voltage: 2S-4S Lipo

• Continuous Current: 35A

• Peak Current: 40A

• ESC Firmware Support: BLHELI_S

• ESC Protocol Support: PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600

• Dimensions: 32mm x 32mm

• Mounting Hole: 25.5mm - 26.5mm

• Net Weight: 7g

Package Includes:

• 1 x HAKRC F4126 BLHELI_S 35A WHOOP AIO FC
