Skystars F7HD Pro5 Flight Controller - 30x30mm

Skystars F7HD Pro5 Flight Controller - 30x30mm

SKU A2-12197
Availability:
in stock
$61.99 - $61.99
$61.99
$61.99 - $61.99
$61.99


The new Skystars F722 HD Pro5 is a flight controller with a modern F7 processor. The fifth generation uses the ICM42688-P gyro, has 16MB of blackbox memory, and both 5V/3A and 10V/3A BECs. The unit also has a connector for DJI Vista, Air Unit 03, or any FPV analog video transmission. The pads for connecting the LEDs are in the corners of the unit and it has an integrated barometer for altitude measurement.

Check out all our 30x30mm Flight Controllers and the rest of our Skystars Products!


Specifications:

  • F722 HDPRO5
  • FC firmware: BETAFLIGHT/INVA/ARDUPILOT
  • Firmware Name: SKST/SKYSTARSF7HDPRO
  • Firmware version: 4.5.2 BTFL
  • Main control MCU: STM32F722
  • Gyro: ICM42688-P
  • Barometer: BMP280
  • OSD MCU: AT7456E
  • Black box: 16MB
  • Motor output: 4ch
  • Servo output: NO
  • LED: Support×4
  • Buzzer: Support
  • Receiver Protocol: ELRS/CRSF/S.BUS/Frsky/
  • Futabafysky/TBS Crossfre/DSMX
  • General serial port: 6ch
  • Output power supply: 3.3V/0.5A,5V/3A,10V/3A
  • USB: Type-C
  • Digital: Support DJI/Vista/walksnail
  • Solderless connector: Brushless ESC 8P
  • DJI port 6P
  • Weight: 9g
  • Dimensions: 39.4mm×39.4mm
  • Installation holes: 30.5mm×30.50/M4
  • Input voltage: 3-6SLiPo(11.1V~22.2V)
  • Including: 1x JST-SH1.0_8p cable
  • 1x JST-SH1.0_6P cable for DJI port
  • 4x Silicon grommets M4 to M3

Package Includes:

  • 1 x Skystars F7HD Pro5 Flight Controller - 30x30mm
